Introduce the installation dimensions of the RV series worm gear reducer

The common models of the RV series worm gear reducer include RV025, RV030, RV040, etc. The following introduces the installation dimensions of some models for you
：

RV030

Overall dimensions: 54mm in length, 80mm in height, and 42mm in thickness (excluding input flange).

Input flange size: 63B14, input hole diameter 11mm, input keyway 4mm, outer frame diameter 90mm, diagonal screw hole diameter 75mm, stopper diameter 60mm, screw diameter 6mm.

RV040

Overall dimensions: 70mm in length, 100mm in height, and 50mm in thickness (excluding input flange).

Enter flange size:

71B5: Input hole diameter 14mm, input keyway 5mm, outer frame diameter 160mm, diagonal screw hole diameter 130mm, stopper diameter 110mm, screw diameter 8.5mm.

71B14: Input hole diameter 14mm, input keyway 5mm, outer frame diameter 105mm, diagonal screw hole diameter 85mm, stopper diameter 70mm, screw diameter 6.5mm.

63B5: Input hole diameter 11mm, input keyway 4mm, outer frame diameter 140mm, diagonal screw hole diameter 115mm, stopper diameter 95mm, screw diameter 9mm.

Output flange size

FA： The outer frame is 95mm in diameter, with a diagonal diameter of 110mm and a diagonal screw hole diameter of 75mm. The length from the center point to the flange edge is 67mm.

FB： The outer frame is 95mm in diameter, with a diagonal diameter of 110mm and a diagonal screw hole diameter of 75mm. The length from the center point to the flange edge is 97mm.

FC： The diagonal diameter of the outer frame is 140mm, the diagonal screw hole diameter of the outer frame is 115mm, and the length from the center point to the flange edge is 80mm.
