What are the installation dimensions of NGW61-6.3 planetary gearbox

The installation dimensions of NGW61-6.3 planetary gearbox usually include the following key parts:

Center distance: refers to the distance between the centers of the input shaft and the output shaft. For NGW61-6.3 planetary reducers, the center distance needs to be determined based on their specific structural design and transmission ratio, and is generally clearly marked in the design drawings or product manuals.

Shaft diameter size: The diameter of the input shaft and output shaft is selected based on the transmitted torque and speed to ensure sufficient strength and stiffness. The length of the input shaft should match the output shaft of the motor, and the length of the output shaft should be determined based on the specific usage scenario, such as connecting equipment, installation position, etc.

Installation bottom dimensions: including the length, width, and thickness of the gearbox installation bottom. There are usually anchor bolt holes on the bottom surface of the installation, and the center distance, diameter, and depth are determined according to the installation environment and foundation structure to ensure the stable installation of the reducer.

Due to differences in design and manufacturing standards among different manufacturers, please refer to the corresponding manufacturer's product samples, manuals, or consult the manufacturer's technical personnel for specific installation dimensions.
