HB series high power hard surface reducer

Product introduction: HB series standard industrial gearbox features: 1.H, B high-power gear reducer adopts universal design scheme, which can be changed into industry-specific gearbox according to customer needs. 2. Realize parallel shaft, orthogonal shaft, vertical and horizontal general-purpose cabinets, with fewer types of parts and more specifications. 3. Adopting a speaker structure and a large cabinet surface

HB series standard industrial gearbox features:

1.H, B high-power gear reducer adopts universal design scheme, which can be transformed into industry-specific gearbox according to customer requirements.

2. Realize parallel shaft, orthogonal shaft, vertical and horizontal general-purpose cabinets, with fewer types of parts and more specifications.

3. Adopting the structure of the suction box body, large cabinet surface area and large fan, cylindrical gear and spiral bevel gear adopt advanced grinding process to improve the temperature rise, noise reduction and reliability of the whole machine. The power is increased.

4. Input mode: motor coupling flange, shaft input.

5. Output mode: solid shaft with flat key, hollow shaft with flat key, hollow shaft with expansion joint, hollow shaft with spline joint, solid shaft with spline joint and solid shaft with flange joint.

6. Installation method: horizontal, vertical, swing base type, torsion arm type.

7.H, B series products have 3 to 26 specifications, the number of reduction transmission stages is 1 to 4, and the speed ratio is 1.25 to 450; and the combination of R, K and S series of our factory has a larger speed ratio.

Technical Parameters:

1. Speed ratio range 1.25-450

2. Torque range 2.6-900kN

3. Power range 4-5000kW

H, B series product structure diagram and product examples:

3.功率范围 4-5000kW

H、B系列产品结构图及产品实例：

H、B系列产品安装尺寸图
