Inch worm gear reducer
  1. Inch worm gear reducer

Inch worm gear reducer

  • Category：Old website product data
    • Inquiry Email
    Description
    NEMA Frame
    LA
    LB
    LC
    LE
    LZ
    Input
    Bore
    Keyway
    56C
    5.875
    4.50
    6.50
    0.16
    0.43
    0.625
    3/16×3/32
    143TC/145TC
    5.875
    4.50
    6.50
    0.16
    0.43
    0.875
    3/16×3/32
    182TC/184TC
    7.250
    8.50
    9.00
    0.23
    0.55
    1.125
    1/4×1/8
    213TC/215TC
    7.250
    8.50
    9.00
    0.23
    0.55
    1.375
    5/16×5/32
    254TC/256TC
    7.250
    8.50
    10.00
    0.23
    0.55
    1.625
    3/8×3/16




    Size

    Radio

    A

    A1

    AB

    AC

    B

    BB

    BD

    40

    5：1
    10：1
    15：1
    20：1
    30：1
    40：1
    50：1
    60：1

    2.58


    3.92

    3.94

    1.85

    3.31

    2.68

    50

    2.85


    4.19

    4.48

    2.08

    3.82

    2.72

    60

    3.15


    4.43

    5.00

    2.20

    4.33

    2.99

    63

    3.37


    4.67

    5.51

    2.36

    4.45

    3.46

    70

    3.76


    4.63

    6.10

    2.52

    5.12

    3.31

    80

    4.11


    5.84

    6.69

    2.85

    5.51

    3.94

    100

    4.78


    6.51

    8.03

    3.33

    6.42

    4.49

    120

    6.10

    8.26

    7.48

    10.24

    3.94

    7.28

    5.04

    135

    6.89

    9.06

    8.32

    11.65

    4.33

    8.27

    5.91

    155

    7.64

    10.24

    9.35

    12.99

    5.20

    9.92

    6.69

    175

    8.78

    11.42

    11.02

    14.57

    5.71

    10.31

    7.32



    Size
    BE
    BF
    CC
    H
    HL
    LL
    Z
    L
    40
    2.13
    3.15
    1.575
    5.00
    1.34
    2.09
    5/16-18
    0.63
    50
    1.97
    3.54
    1.969
    5.91
    1.38
    2.56
    5/16-18
    0.63
    60
    2.13
    3.94
    2.362
    6.97
    1.65
    2.95
    3/8-16
    0.75
    63
    2.69
    4.87
    2.480
    7.32
    1.89
    2.95
    3/8-16
    0.75
    70
    2.56
    4.92
    2.756
    8.46
    2.16
    3.54
    3/8-16
    0.75
    80
    2.76
    5.51
    3.150
    9.84
    2.56
    4.13
    3/8-16
    0.75
    100
    3.54
    7.09
    3.937
    12.20
    3.15
    5.12
    1/2-13
    0.94
    120
    3.94
    8.66
    4.724
    14.57
    3.74
    6.10
    1/2-13
    0.94
    135
    4.33
    10.24
    5.315
    16.73
    4.13
    7.28
    5/8-11
    1.13
    155
    4.72
    11.02
    6.102
    18.15
    4.05
    7.99
    5/8-11
    1.13
    175
    5.51
    12.60
    6.890
    20.51
    4.84
    8.78
    3/4-10
    1.38
