The company manufactures nearly 30 types of over 140 agitators, ranging from the most common (including the existing HB5 standard, SB90 standard agitators) to a variety of complex shapes or special purpose agitators. According to H/ t2123-91 standard various specifications of the series of manufacturing, or according to the production process requirements of users, design and manufacture of agitator for a variety of special requirements, special specifications or special USES.
Toothed disc turbine agitator
Flat Toothed Disc Turbine CY, Flanged Disc Turbine FY, Toothed Disc Turbine TY
The outer edge of the disc has a zigzag shape, and the shearing performance is high under high-speed rotation. The cycle ability is relatively weak, the dispersion, pulverization and stripping are strong, and the two-phase physical property difference is suitable for the dispersion mixing, such as the dispersion process of the paint. The flat tooth shape is a horizontal sawtooth, and the toothed shape and the toothed shape are upper and lower vertical serrations. The former is the tooth and the disc are integrally punched up and down, the teeth are rough, and the latter is the two oversaw strip welding. The outer edge of the disc is fine. Common medium viscosity μ <50000 cp, common operating speed n=100-1000 rpm, v=5-20 m/s, common size DJ/D=0.2-0.5.
