YTC series gear reduction three-phase asynchronous motor
  1. YTC series gear reduction three-phase asynchronous motor

YTC series gear reduction three-phase asynchronous motor

  • Category:Old website product data
  • Inquiry Email
    Description

    YTC gear reduction three-phase asynchronous motor product features

    YTC series gear reduction three-phase asynchronous motor is designed to meet the needs of driving low-speed transmission machinery. It has the characteristics of low spindle speed and large torque, and its structure is firm and easy to use. It is general mine, metallurgy, sugar, paper, chemical industry. , rubber and other industrial and infrastructure sites are commonly used. This series of motors can be connected to the transmission by a coupling or spur gear. The motor is started directly at full pressure.

    YTC gear reduction three-phase asynchronous motor use conditions and marking examples

    Conditions of Use

    This series of motors has a common type and a damp heat type. Normal type is suitable for cooling medium temperature not higher than 40 C. The damp heat type is added with the word “TH” after the normal type. It has the same performance index and shape installation size as the normal type, and can be used for the relative humidity of not more than 95% (25 C), with condensation and mold environment. . Rated voltage: 380 volts (for power supply of 3KW or less, Y connection, others are connected) Rated frequency: 50 Hz Working system: continuous
