What specific working conditions are suitable for B-series gearboxes

1. Core application industries and scenarios

The B-series gearbox is generally suitable for high-power and high torque working conditions, mainly covering more than ten industries as follows:

Heavy load and impact load scenarios: Excellent performance in metallurgical, mining, lifting, and other scenarios that require significant impact loads and long-term continuous operation.

Large scale basic industries: suitable for conventional heavy-duty continuous working conditions such as steel, building materials, cement, chemical, and electricity.

High torque and long service life requirements: Meet the strict requirements for high power, high torque, and long service life of port machinery, ships, large conveyors, and other working conditions.

Medium load and confined space: The partially optimized B-series gearbox has a compact structure, good noise control, and optimized heat dissipation, and is also suitable for medium load and limited installation space scenarios such as light industry, environmental protection, and energy equipment.

2. Adapt to special working conditions and environments

90 ° steering transmission: The B series is a straight axis (spiral bevel gear+helical gear combination) structure, specifically designed for power transmission scenarios that require a 90 ° steering between the input and output shafts.

Harsh and dusty environment: The sealing design adopts a combination of labyrinth and double lip oil seal, which is dustproof and leak proof, suitable for harsh working conditions such as high dust.

High heat dissipation and low noise requirements: The enclosure adopts a sound-absorbing structure, a large heat dissipation area design, and is equipped with a forced fan, suitable for working conditions that require temperature rise and noise control during operation.

Narrow space installation: Some models can provide flange type output shafts to meet the installation requirements in narrow spaces.

3. Scope of application of technical parameters

When selecting, the B-series gearbox is suitable for operating conditions within the following parameter range:

Power range: 2.8 kW to 3000 kW

Torque range: 5.8 kN · m to 900 kN · m

Speed ratio range: 5-400 (can be combined with R and K series to obtain larger speed ratios)

Selection suggestion: In actual working conditions, it is recommended to match according to the specific equipment power and output torque. If there are significant impact loads or frequent start stop situations in the operating conditions, it is recommended to choose a usage factor of 1.5 or above to ensure safe operation.
