What are the specific consequences if the reverse stopper of ZSY reducer is installed

1、 Core function failure

The backstop is a one-way locking device, and its internal structure (such as wedges and rollers) has clear directionality. Once installed in reverse, in working conditions where the equipment needs to prevent reversal (such as shutdown or power outage), the backstop not only fails to lock, but also remains in a "free" state, causing the equipment to reverse under the action of load gravity or inertia.

2、 Risk of equipment damage

Self scrapping of backstop: After installation, key components such as claws, ratchet wheels, springs, or rollers inside the backstop will be subjected to abnormal reverse impact forces, leading to rapid local wear and even fracture and tooth damage, resulting in direct scrapping of the backstop.

Damage to related components: Abnormal vibrations and impact loads caused by reverse failure will be transmitted to ZSY reducers, motors, and other equipment through the transmission shaft, accelerating the wear of precision components such as bearings and gears and shortening the service life of the entire machine.

Abnormal shutdown: Reverse installation of the backstop may cause additional resistance or jamming of the equipment during operation, triggering motor overload protection, causing unplanned shutdown, affecting production efficiency, and potentially damaging the electrical system.

3、 Serious safety accidents

This is the most dangerous consequence of installing a reverse check device. On key equipment such as elevators and inclined belt conveyors, reverse failure can lead to:

Material backflow and falling: The load is out of control and reversed, causing material accumulation, scattering, and even falling from a height.

Mechanical injury: Components that undergo high-speed reversal may fly out or cause serious mechanical injury to surrounding operators during the reversal process.

Major production accidents: In scenarios such as mines and power plants, equipment reversal may cause malignant accidents such as belt tearing, drum damage, and tail burial, resulting in significant casualties and property losses.
