The advantages of ZS85-160-III soft tooth surface gear reducer include smooth transmission, strong adaptability, and low manufacturing and maintenance costs. The main disadvantages are limited load-bearing capacity and short service life, as follows: advantage: Smooth transmission and low noise: Soft tooth surface reducers usually use involute helical cylindrical gear transmission, which mak
Hard tooth surface gear reducers are suitable for heavy-duty and high torque demand applications, such as metallurgy, mining, and other industries; Soft tooth surface gear reducers are mostly used in scenarios with light loads and high noise requirements, such as textile machinery, food packaging machinery, etc. Specifically, as follows: Applicable scenarios for hard tooth surface gear reducers
When applying lubricating grease to the ZQ500-23.34-3CA cylindrical gear reducer, the following methods and precautions can be referred to: Preparation before application: Use appropriate mechanical cleaning agents and tools to thoroughly clean the parts of the gearbox that need to be lubricated, such as gears, bearings, etc., to ensure that there is no oil, dust, or impurities, and to avoid mo
When installing the ZQ400 soft tooth surface reducer, the coaxiality between the motor shaft and the reducer input shaft can be checked by the following methods: Steel ruler and plug gauge inspection method: Place the steel ruler on the large outer circle parallel to the axis of the coupling, making it at a 90 ° angle to the axis, and continuously inspect three points. If the gap between the st
Optimizing the structural design of TY80-114-1.5KW reducer to reduce vibration can be achieved by starting from aspects such as gear system, bearings and shaft system, and box structure. The specific methods are as follows: Optimization of gear system Using helical gears: Replace spur gears with helical gears, and recommend helical gears with a helix angle of ≥ 15 °. This can increase the nu
The standardized installation of TY160-25-11KW reducer can refer to the following methods: Preparation before installation: Tools and materials: Prepare a torque wrench with the required accuracy (error ≤ ± 3%), and select according to the specifications of the gearbox bolts. For example, M8 bolts can correspond to a torque of 25-30N · m. Use a laser alignment instrument (accuracy ≤ 0.01mm/m
The adjustment of the eccentric sleeve of XLDY8225-47-22KW cycloidal pinwheel reducer is usually to change the motion trajectory of the cycloidal gear or adjust the reduction ratio. Common adjustment methods include loosening the locking screw adjustment method, gasket adjustment method, etc. The specific operation steps are as follows: Loosen the locking screw adjustment method: Expose ecce
In addition to the eccentric sleeve adjustment method, XLE8215A-273 cycloidal pinwheel reducer can also use gasket adjustment method, eccentric shaft replacement method, axial clearance adjustment method, and concentricity adjustment method, as follows: Shim adjustment method: By changing the number or thickness of shims between the bearing and the shaft or between the bearing and the bearing s
